Application:
● Geometrical tolerance measurement of
metal components/welding parts
● Quick measurement on site to select onspec. components
Feature:
● Position accuracy measurement up to 0.5mm
● Profile accuracy measurement up to 0.5mm
● Gauge datum-plane / pins hardness ＞ HRC
 58, high durability.
● Fit clearance of pins with accuracy ＜ 0.005mm
● One gauge covering all measuring data, more
 efficient
● Gauge plan and solutions according to your
 drawings
